10Ton 10TPD Oil Sludge Waste Tire Pyrolysis Oil To Diesel Oil
Refinery Device
Waste engine oil /pyrolysis oil can be refined into valuable diesel
oil through catalytic cracking and high temperature distillation
technology. It is a method of separating mixtures based on
differences in volatilities of components in a boiling liquid
mixture. After being distilled by the distillation plant, the oil
may have dark color with bad smell, then we suggest to deep purify
the oil, with Jinzhen matched color and smell removal system, you
will get clean diesel oil as final products with beautiful light
yellow color.
This machine will need one-time catalyst which is produced by our
company only, there is no need to buy from other catalyst factory
as we have the catalyst formula .it is customized.
The pyrolysis oil with black color after distillation and remove
color and smell , we will get synthetic diesel oil with yellow
color,which can be used for diesel engines like trucks , tractors ,
ships etc.
| No. | End Production | Yield | Usage |
| 1 | Diesel | 73% | Used for diesel engine |
| 2 | Gasoline | 12% | Used for gasoline engine |
| 3 | Residue Oil | 9% | * Feeding into Pyrolysis Machine for second Pyrolysis
* Sold directly for building road |
| 4 | Non-Condensible Gas | 3% | Recycle as Heating fuel after treated by Gas-treatment System |
| 5 | Other | 3% | * Water and impurity 2%
* Loss 1% |
Technical Specification
| Waste Oil into Diesel Distillation Machine |
| 5TPD, 10TPD, 20TPD, 50TPD,100TPD,300TPD |
| Q345R, Alloy Steel, Stainless Steel |
| 16.45mm, 18.45mm |
| 80-300 tons (Varies by Design and Capacity) |
| 45-450KW(Varies by Design and Capacity) |
| 4-15 Persons for per set machine, more machine, fewer labors |
| Feeding Raw Material, Heating and Reacting, Sludge Oil Discharging |
| Fuel Oil, Used Engine Oil, Heavy Oil, Tower Bottom Residue Oil,
Waste Tyre Oil, Waste Hydraulic Oil,Crude Oil, Waste Plastic Oil,
etc... |
| Pyrolysis Oil, Natural Gas, Electricity, Coal, Firewood, etc... |
Working process of waste engine oil distillation machine
Work process
Using the oil pump to put the waste oil to the main reactor and the
oil will be heated by high temperature and turns to be gas . Going
through the cooling system for cooling down and getting heavy
diesel here.
The main list of waste oil distillation equipment
A. Vertical reactor/Horizontal reactor
B. Reducer system
C. Condensation system
D. Collector
E. Oil collecting tank
F. Residue tank
G. Oil-gas separator
H. Water cooling system
I. Water seal
J. Pressure & Temperature monitoring gauge
K. Deodorization system
L. Efficient anti clog cooling system
M. Gas heating system (waste gas process system)
N. Smoke desulphurization and dust removal system
Technological Process
Raw oil after dewater process goes into reactor. Heating, gasifying
and cooling to get petrol and diesel component.
After heating and gasifying, Petrol gas expels from top outlet of
catalyze tower, and goes into petrol storage tank after cooling
through
condenser.Then inject petrol into another big storage tank.
After heating and gasifying, Diesel gas expels from top outlet of
catalyze tower, and goes into diesel storage tank after cooling
through
condenser. Then inject diesel into another big storage tank.
Distilled diesel after treatment by oil reconcile tank,will
becoming fuel oil with high quality.
A little of flammable gas go through medium tank and into exhaust
gas treatment equipment to be processed. And then go through water
deal
into furnace to burn.
After-sales service
1.Engineers with over ten years’ waste to oil recycling experience
will be dispatched to your place to provide technical service in
guiding plant installation, plant commissioning as well as worker
training.
2.We all know that good plant design and quality are essential, and
good installation and training service are as important as or even
more important than good plant design and quality. It is very
dangerous if clients can not install or run the plant properly.
3.So, after plant installation finishes, our engineers are required
to help you run the plant for at least 15 batches, enabling your
workers to master all the operating skills needed and then operate
the plant on their own.
FAQ of waste engine oil distillation machine
Q: Are there any bad smell or odor from waste tyre oil distillation
equipment while distillation system is working?
A: There will be no smell at all as the gas produced by waste oil
distillation plant will be purified by our exclusive tail gas
purification unit before emission.
Q: What is the yield of this waste tyre oil distillation equipment?
A: Typically the yield of our waste oil distillation plant is
between 85-90% (depending on variations of water content, light HC
and others ingredients from waste oil.)
Q: How many areas are required to build the waste tyre oil
distillation equipment?
A: The land area required usually depends on the capacity of your
plant. We can calculate the area needed and give you the plant
designs.
Q: What is the warranty of the waste tyre oil distillation
equipment?
A: 12 months free guanantee and life long standard paid service.
Q: Can you install the production line and train our stuffs?
A: Yes we can. We'll send engineers to help you install the waste
oil distillation plant and train your workers until the machine is
skillfully operated.
